Fiber Laser Cutting Machine
High-power precision cutting for sheet metal, tubes, and plates. From prototype to full production — clean cuts, minimal waste.
Our Fiber Laser Cutting Machines deliver industrial-grade cutting performance for sheet metal fabrication. Featuring high-power fiber laser sources from 1kW to 12kW, these systems achieve exceptional cut quality and speed across carbon steel, stainless steel, aluminum, brass, and copper.
With automatic focusing heads, intelligent nesting software, and exchangeable worktables, our cutting systems maximize throughput while minimizing material waste. The enclosed cabinet design ensures operator safety and efficient fume extraction.
Available in multiple worktable sizes to suit any production requirement, from small job shops to high-volume manufacturing facilities.
Key Features
Technical Specifications
| Parameter | Specification |
|---|---|
| Laser Type | Fiber Laser (CW) |
| Laser Power | 1kW / 2kW / 3kW / 6kW / 12kW |
| Working Area | 1500×3000mm / 2000×4000mm / 2000×6000mm |
| Max Cutting Thickness (CS) | Up to 25mm (6kW) / 40mm (12kW) |
| Max Cutting Thickness (SS) | Up to 15mm (6kW) / 25mm (12kW) |
| Positioning Accuracy | ±0.03 mm/m |
| Max Acceleration | 1.5G |
| Max Speed | 120 m/min |
| Cutting Head | Auto-focus, capacitive sensing |
| Assist Gas | O₂, N₂, Compressed Air |
| Cooling | Water Chiller (included) |
| Control System | CypCut / FSCUT |
Applications
Interested in this Fiber Laser Cutting Machine?
Contact our team for pricing, technical specifications, and customization options.
